JAVA与PLC通信示例代码：实现高效可靠的跨平台数据交互

Java作为跨平台编程语言，在工业自动化上位机开发中应用广泛。通过Modbus协议，Java程序可以与各种品牌的PLC（西门子、三菱、台达、欧姆龙等）进行高效可靠的数据交互。本文提供完整的Java与PLC通信示例代码，包括Modbus TCP客户端实现、多PLC管理、数据采集、断线重连、批量读写、浮点数处理以及Spring Boot集成方案。

一、Java Modbus通信方案选型

1.1 常用Java Modbus库对比

1.2 本文使用EasyModbus

EasyModbus是目前最活跃、API最简洁的Java Modbus库，支持TCP、RTU和UDP协议，既可作为客户端也可作为服务端，文档完善，适合大多数项目。

<!-- Maven依赖 -->
<dependency>
    <groupId>com.github.s7connector</groupId>
    <artifactId>easymodbus</artifactId>
    <version>1.0.0</version>
</dependency>

<!-- 串口支持（RTU模式需要） -->
<dependency>
    <groupId>com.fazecast</groupId>
    <artifactId>jSerialComm</artifactId>
    <version>2.9.2</version>
</dependency>

二、Modbus TCP客户端封装

package com.industrial.modbus;

import de.re.easymodbus.modbusclient.ModbusClient;
import de.re.easymodbus.datatypes.DataType;
import java.io.IOException;
import java.net.SocketException;
import java.util.Arrays;
import java.util.concurrent.atomic.AtomicBoolean;

/**
 * Modbus TCP客户端封装
 * 支持连接管理、自动重连、批量读写、数据类型转换
 */
public class PlcModbusClient {

    private final String ipAddress;
    private final int port;
    private final int unitId;
    private ModbusClient client;
    private final AtomicBoolean connected = new AtomicBoolean(false);
    private Thread reconnectThread;
    private volatile boolean running = true;

    // 连接参数
    private static final int CONNECT_TIMEOUT = 3000;
    private static final int RECONNECT_INTERVAL = 5000;
    private static final int MAX_RETRY = 3;

    public PlcModbusClient(String ipAddress, int port, int unitId) {
        this.ipAddress = ipAddress;
        this.port = port;
        this.unitId = unitId;
    }

    /**
     * 连接PLC
     */
    public synchronized boolean connect() {
        try {
            if (client != null && client.isConnected()) {
                return true;
            }
            client = new ModbusClient(ipAddress, port);
            client.setConnectionTimeout(CONNECT_TIMEOUT);
            client.setUnitIdentifier(unitId);
            client.Connect();
            connected.set(true);
            System.out.printf("[%s:%d] PLC连接成功，从站地址：%d%n",
                ipAddress, port, unitId);
            return true;
        } catch (Exception e) {
            connected.set(false);
            System.err.printf("[%s:%d] 连接失败：%s%n", ipAddress, e.getMessage());
            return false;
        }
    }

    /**
     * 断开连接
     */
    public synchronized void disconnect() {
        running = false;
        if (reconnectThread != null) {
            reconnectThread.interrupt();
        }
        try {
            if (client != null && client.isConnected()) {
                client.Disconnect();
            }
        } catch (IOException e) {
            // 忽略
        }
        connected.set(false);
        System.out.printf("[%s:%d] 连接已关闭%n", ipAddress);
    }

    /**
     * 启动自动重连
     */
    public void startAutoReconnect() {
        reconnectThread = new Thread(() -> {
            while (running) {
                try {
                    if (!isConnected()) {
                        System.out.printf("[%s:%d] 检测到断开，尝试重连...%n", ipAddress);
                        connect();
                    }
                    Thread.sleep(RECONNECT_INTERVAL);
                } catch (InterruptedException e) {
                    break;
                }
            }
        }, "Modbus-Reconnect-" + ipAddress);
        reconnectThread.setDaemon(true);
        reconnectThread.start();
    }

    /**
     * 检查连接状态
     */
    public boolean isConnected() {
        if (client == null) return false;
        try {
            // 发送一个简单的读请求测试连接
            client.ReadHoldingRegisters(0, 1);
            return true;
        } catch (Exception e) {
            connected.set(false);
            return false;
        }
    }

    // ==================== 读操作 ====================

    /**
     * 读保持寄存器（功能码03）
     */
    public int[] readHoldingRegisters(int startAddr, int count) throws IOException {
        for (int retry = 0; retry < MAX_RETRY; retry++) {
            try {
                ensureConnected();
                return client.ReadHoldingRegisters(startAddr, count);
            } catch (SocketException e) {
                connected.set(false);
                if (retry < MAX_RETRY - 1) {
                    connect();
                    continue;
                }
                throw e;
            }
        }
        throw new IOException("读取失败，重试次数超限");
    }

    /**
     * 读输入寄存器（功能码04）
     */
    public int[] readInputRegisters(int startAddr, int count) throws IOException {
        ensureConnected();
        return client.ReadInputRegisters(startAddr, count);
    }

    /**
     * 读线圈（功能码01）
     */
    public boolean[] readCoils(int startAddr, int count) throws IOException {
        ensureConnected();
        return client.ReadCoils(startAddr, count);
    }

    /**
     * 读离散输入（功能码02）
     */
    public boolean[] readDiscreteInputs(int startAddr, int count) throws IOException {
        ensureConnected();
        return client.ReadDiscreteInputs(startAddr, count);
    }

    // ==================== 写操作 ====================

    /**
     * 写单个寄存器（功能码06）
     */
    public void writeSingleRegister(int addr, int value) throws IOException {
        ensureConnected();
        client.WriteSingleRegister(addr, value);
    }

    /**
     * 写多个寄存器（功能码16）
     */
    public void writeMultipleRegisters(int startAddr, int[] values) throws IOException {
        ensureConnected();
        client.WriteMultipleRegisters(startAddr, values);
    }

    /**
     * 写单个线圈（功能码05）
     */
    public void writeSingleCoil(int addr, boolean value) throws IOException {
        ensureConnected();
        client.WriteSingleCoil(addr, value);
    }

    /**
     * 写多个线圈（功能码15）
     */
    public void writeMultipleCoils(int startAddr, boolean[] values) throws IOException {
        ensureConnected();
        client.WriteMultipleCoils(startAddr, values);
    }

    // ==================== 数据类型转换 ====================

    /**
     * 读取32位有符号整数（占用2个寄存器）
     */
    public int readInt32(int startAddr) throws IOException {
        int[] regs = readHoldingRegisters(startAddr, 2);
        return (regs[0] << 16) | (regs[1] & 0xFFFF);
    }

    /**
     * 读取32位无符号整数
     */
    public long readUInt32(int startAddr) throws IOException {
        int[] regs = readHoldingRegisters(startAddr, 2);
        return ((long)(regs[0] & 0xFFFF) << 16) | (regs[1] & 0xFFFF);
    }

    /**
     * 读取32位浮点数
     */
    public float readFloat32(int startAddr) throws IOException {
        int[] regs = readHoldingRegisters(startAddr, 2);
        int bits = (regs[0] << 16) | (regs[1] & 0xFFFF);
        return Float.intBitsToFloat(bits);
    }

    /**
     * 读取64位浮点数（占用4个寄存器）
     */
    public double readFloat64(int startAddr) throws IOException {
        int[] regs = readHoldingRegisters(startAddr, 4);
        long bits = ((long)(regs[0] & 0xFFFF) << 48) |
                    ((long)(regs[1] & 0xFFFF) << 32) |
                    ((long)(regs[2] & 0xFFFF) << 16) |
                    (regs[3] & 0xFFFF);
        return Double.longBitsToDouble(bits);
    }

    /**
     * 读取字符串（占用N个寄存器，每个寄存器存2个字符）
     */
    public String readString(int startAddr, int registerCount) throws IOException {
        int[] regs = readHoldingRegisters(startAddr, registerCount);
        StringBuilder sb = new StringBuilder();
        for (int reg : regs) {
            char high = (char)((reg >> 8) & 0xFF);
            char low = (char)(reg & 0xFF);
            if (high != 0) sb.append(high);
            if (low != 0) sb.append(low);
        }
        return sb.toString().trim();
    }

    /**
     * 写入32位浮点数
     */
    public void writeFloat32(int startAddr, float value) throws IOException {
        int bits = Float.floatToIntBits(value);
        int[] regs = new int[2];
        regs[0] = (bits >> 16) & 0xFFFF;
        regs[1] = bits & 0xFFFF;
        writeMultipleRegisters(startAddr, regs);
    }

    private void ensureConnected() throws IOException {
        if (!connected.get() || client == null || !client.isConnected()) {
            if (!connect()) {
                throw new IOException("PLC未连接：" + ipAddress);
            }
        }
    }

    public String getIpAddress() { return ipAddress; }
    public int getPort() { return port; }
    public int getUnitId() { return unitId; }
}

三、多PLC管理

package com.industrial.modbus;

import java.io.IOException;
import java.util.Map;
import java.util.concurrent.ConcurrentHashMap;

/**
 * 多PLC连接管理器
 * 支持多台PLC的统一管理、批量数据采集
 */
public class PlcConnectionManager {

    private final Map<String, PlcModbusClient> connections = new ConcurrentHashMap<>();

    /**
     * 添加PLC连接
     */
    public void addPlc(String name, String ip, int port, int unitId) {
        PlcModbusClient client = new PlcModbusClient(ip, port, unitId);
        connections.put(name, client);
        if (client.connect()) {
            client.startAutoReconnect();
        }
    }

    /**
     * 获取PLC客户端
     */
    public PlcModbusClient getPlc(String name) {
        return connections.get(name);
    }

    /**
     * 批量读取所有PLC的指定寄存器
     */
    public Map<String, int[]> batchReadHoldingRegisters(int startAddr, int count) {
        Map<String, int[]> results = new ConcurrentHashMap<>();
        connections.forEach((name, client) -> {
            try {
                int[] values = client.readHoldingRegisters(startAddr, count);
                results.put(name, values);
            } catch (IOException e) {
                System.err.printf("读取PLC[%s]失败：%s%n", name, e.getMessage());
            }
        });
        return results;
    }

    /**
     * 断开所有连接
     */
    public void disconnectAll() {
        connections.values().forEach(PlcModbusClient::disconnect);
        connections.clear();
    }

    /**
     * 获取连接状态
     */
    public Map<String, Boolean> getConnectionStatus() {
        Map<String, Boolean> status = new ConcurrentHashMap<>();
        connections.forEach((name, client) -> {
            status.put(name, client.isConnected());
        });
        return status;
    }
}

四、数据采集服务

package com.industrial.modbus;

import java.io.IOException;
import java.util.*;
import java.util.concurrent.*;

/**
 * PLC数据采集服务
 * 定时采集PLC数据，支持数据缓存、变化检测、回调通知
 */
public class PlcDataCollector {

    private final PlcModbusClient client;
    private final ScheduledExecutorService scheduler = Executors.newSingleThreadScheduledExecutor();
    private final Map<String, Object> dataCache = new ConcurrentHashMap<>();
    private final List<DataChangeListener> listeners = new CopyOnWriteArrayList<>();
    private volatile boolean running = false;

    // 采集配置
    private final List<CollectItem> collectItems = new ArrayList<>();

    public interface DataChangeListener {
        void onDataChanged(String key, Object oldValue, Object newValue);
    }

    static class CollectItem {
        String key;
        int address;
        String type;  // INT16, INT32, FLOAT32, COIL

        CollectItem(String key, int address, String type) {
            this.key = key;
            this.address = address;
            this.type = type;
        }
    }

    public PlcDataCollector(PlcModbusClient client) {
        this.client = client;
    }

    /**
     * 添加采集项
     */
    public void addCollectItem(String key, int address, String type) {
        collectItems.add(new CollectItem(key, address, type));
    }

    /**
     * 添加数据变化监听器
     */
    public void addDataChangeListener(DataChangeListener listener) {
        listeners.add(listener);
    }

    /**
     * 启动定时采集
     */
    public void start(long intervalMs) {
        running = true;
        scheduler.scheduleAtFixedRate(this::collectAll, 0, intervalMs, TimeUnit.MILLISECONDS);
        System.out.println("数据采集服务已启动，间隔：" + intervalMs + "ms");
    }

    /**
     * 停止采集
     */
    public void stop() {
        running = false;
        scheduler.shutdown();
        System.out.println("数据采集服务已停止");
    }

    /**
     * 采集所有数据
     */
    private void collectAll() {
        if (!running) return;

        for (CollectItem item : collectItems) {
            try {
                Object value = readValue(item);
                Object oldValue = dataCache.put(item.key, value);

                // 检测变化并通知
                if (oldValue == null || !oldValue.equals(value)) {
                    final Object finalOldValue = oldValue;
                    final Object finalValue = value;
                    listeners.forEach(l -> l.onDataChanged(item.key, finalOldValue, finalValue));
                }
            } catch (Exception e) {
                System.err.printf("采集[%s]失败：%s%n", item.key, e.getMessage());
            }
        }
    }

    private Object readValue(CollectItem item) throws IOException {
        switch (item.type) {
            case "INT16":
                return client.readHoldingRegisters(item.address, 1)[0];
            case "INT32":
                return client.readInt32(item.address);
            case "FLOAT32":
                return client.readFloat32(item.address);
            case "COIL":
                return client.readCoils(item.address, 1)[0];
            default:
                throw new IllegalArgumentException("不支持的数据类型：" + item.type);
        }
    }

    /**
     * 获取缓存数据
     */
    public Map<String, Object> getAllData() {
        return new HashMap<>(dataCache);
    }

    /**
     * 获取单个数据
     */
    public Object getData(String key) {
        return dataCache.get(key);
    }
}

五、完整使用示例

package com.industrial.modbus;

import java.util.Arrays;
import java.util.Map;

public class PlcCommunicationDemo {

    public static void main(String[] args) {
        // 1. 创建PLC客户端
        PlcModbusClient plc = new PlcModbusClient("192.168.1.100", 502, 1);

        try {
            // 2. 连接PLC
            if (!plc.connect()) {
                System.err.println("无法连接到PLC");
                return;
            }
            plc.startAutoReconnect();
            System.out.println("PLC连接成功！\n");

            // 3. 读取保持寄存器
            System.out.println("=== 读取保持寄存器 ===");
            int[] regs = plc.readHoldingRegisters(0, 10);
            System.out.println("D0-D9：" + Arrays.toString(regs));

            // 4. 读取浮点数
            System.out.println("\n=== 读取浮点数 ===");
            float temperature = plc.readFloat32(10);
            float humidity = plc.readFloat32(12);
            System.out.printf("温度：%.2f℃%n", temperature);
            System.out.printf("湿度：%.2f%%%n", humidity);

            // 5. 读取32位整数
            System.out.println("\n=== 读取32位整数 ===");
            int counter = plc.readInt32(20);
            System.out.println("计数器值：" + counter);

            // 6. 读取线圈
            System.out.println("\n=== 读取线圈 ===");
            boolean[] coils = plc.readCoils(0, 8);
            for (int i = 0; i < coils.length; i++) {
                System.out.printf("M%d：%s%n", i, coils[i] ? "ON" : "OFF");
            }

            // 7. 读取离散输入
            System.out.println("\n=== 读取离散输入 ===");
            boolean[] inputs = plc.readDiscreteInputs(0, 4);
            for (int i = 0; i < inputs.length; i++) {
                System.out.printf("X%d：%s%n", i, inputs[i] ? "ON" : "OFF");
            }

            // 8. 写入寄存器
            System.out.println("\n=== 写入寄存器 ===");
            plc.writeSingleRegister(100, 1234);
            System.out.println("D100 写入 1234");

            int check = plc.readHoldingRegisters(100, 1)[0];
            System.out.println("D100 回读：" + check);

            // 9. 批量写入
            plc.writeMultipleRegisters(200, new int[]{100, 200, 300, 400});
            System.out.println("D200-D203 批量写入完成");

            // 10. 写入浮点数
            plc.writeFloat32(300, 25.5f);
            System.out.println("D300 写入浮点数 25.5");
            float readBack = plc.readFloat32(300);
            System.out.printf("D300 回读：%.2f%n", readBack);

            // 11. 控制线圈
            System.out.println("\n=== 控制线圈 ===");
            plc.writeSingleCoil(0, true);
            System.out.println("M0 置为 ON");
            Thread.sleep(500);
            plc.writeSingleCoil(0, false);
            System.out.println("M0 置为 OFF");

            // 12. 批量控制线圈
            plc.writeMultipleCoils(10, new boolean[]{true, false, true, false});
            System.out.println("M10-M13 批量写入完成");

            // 13. 读取字符串
            System.out.println("\n=== 读取字符串 ===");
            String deviceName = plc.readString(400, 10);
            System.out.println("设备名称：" + deviceName);

        } catch (Exception e) {
            System.err.println("通讯异常：" + e.getMessage());
            e.printStackTrace();
        } finally {
            plc.disconnect();
            System.out.println("\nPLC连接已关闭");
        }
    }
}

六、数据采集服务使用示例

package com.industrial.modbus;

public class DataCollectorDemo {

    public static void main(String[] args) throws InterruptedException {
        // 创建PLC客户端
        PlcModbusClient plc = new PlcModbusClient("192.168.1.100", 502, 1);
        plc.connect();
        plc.startAutoReconnect();

        // 创建数据采集服务
        PlcDataCollector collector = new PlcDataCollector(plc);

        // 添加采集项
        collector.addCollectItem("temperature", 10, "FLOAT32");
        collector.addCollectItem("humidity", 12, "FLOAT32");
        collector.addCollectItem("pressure", 14, "FLOAT32");
        collector.addCollectItem("counter", 20, "INT32");
        collector.addCollectItem("status", 0, "COIL");
        collector.addCollectItem("mode", 50, "INT16");

        // 添加数据变化监听器
        collector.addDataChangeListener((key, oldValue, newValue) -> {
            System.out.printf("[数据变化] %s: %s -> %s%n", key, oldValue, newValue);
        });

        // 启动采集，每1秒采集一次
        collector.start(1000);

        // 运行30秒
        Thread.sleep(30000);

        // 打印当前所有数据
        System.out.println("\n=== 当前数据快照 ===");
        collector.getAllData().forEach((k, v) -> System.out.printf("%s = %s%n", k, v));

        // 停止采集
        collector.stop();
        plc.disconnect();
    }
}

七、Spring Boot集成

package com.industrial.config;

import com.industrial.modbus.PlcModbusClient;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;

@Configuration
public class ModbusConfig {

    @Value("${modbus.plc.ip:192.168.1.100}")
    private String plcIp;

    @Value("${modbus.plc.port:502}")
    private int plcPort;

    @Value("${modbus.plc.unit-id:1}")
    private int unitId;

    @Bean(destroyMethod = "disconnect")
    public PlcModbusClient plcModbusClient() {
        PlcModbusClient client = new PlcModbusClient(plcIp, plcPort, unitId);
        if (client.connect()) {
            client.startAutoReconnect();
        }
        return client;
    }
}

// Service层
package com.industrial.service;

import com.industrial.modbus.PlcModbusClient;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.stereotype.Service;

import java.io.IOException;
import java.util.HashMap;
import java.util.Map;

@Service
public class PlcDataService {

    @Autowired
    private PlcModbusClient plc;

    /**
     * 获取设备运行数据
     */
    public Map<String, Object> getDeviceData() throws IOException {
        Map<String, Object> data = new HashMap<>();
        data.put("temperature", plc.readFloat32(10));
        data.put("humidity", plc.readFloat32(12));
        data.put("pressure", plc.readFloat32(14));
        data.put("runningHours", plc.readInt32(20));
        data.put("status", plc.readCoils(0, 1)[0]);
        return data;
    }

    /**
     * 设置温度设定值
     */
    public void setTemperature(float value) throws IOException {
        plc.writeFloat32(100, value);
    }

    /**
     * 启动设备
     */
    public void startDevice() throws IOException {
        plc.writeSingleCoil(0, true);
    }

    /**
     * 停止设备
     */
    public void stopDevice() throws IOException {
        plc.writeSingleCoil(0, false);
    }
}

// Controller层
package com.industrial.controller;

import com.industrial.service.PlcDataService;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.*;

import java.io.IOException;
import java.util.Map;

@RestController
@RequestMapping("/api/plc")
public class PlcController {

    @Autowired
    private PlcDataService plcService;

    @GetMapping("/data")
    public Map<String, Object> getData() throws IOException {
        return plcService.getDeviceData();
    }

    @PostMapping("/temperature")
    public String setTemperature(@RequestParam float value) throws IOException {
        plcService.setTemperature(value);
        return "温度设定值已更新为：" + value;
    }

    @PostMapping("/start")
    public String start() throws IOException {
        plcService.startDevice();
        return "设备已启动";
    }

    @PostMapping("/stop")
    public String stop() throws IOException {
        plcService.stopDevice();
        return "设备已停止";
    }
}

八、常见问题与最佳实践

8.1 常见问题

• 连接超时：检查PLC IP地址、端口、防火墙，确认PLC在线且Modbus TCP已启用
• 返回异常码02：地址越界，确认读取的地址范围在PLC支持范围内
• 返回异常码03：数据值非法，检查写入的值是否超出范围
• 浮点数解析错误：尝试不同的字节序（ABCD/CDAB/DCBA/BADC）
• 并发冲突：多线程访问同一连接时使用synchronized或独立连接
• 连接断开：启用自动重连，网络恢复后自动恢复通讯
• 中文乱码：字符串读取时注意字符编码，PLC中通常使用GBK或ASCII

8.2 最佳实践

• 批量读取：尽量一次读取多个连续寄存器，减少通讯次数，提高效率
• 合理轮询间隔：建议不小于100ms，避免过快轮询导致PLC通讯过载
• 自动重连：生产环境必须启用自动重连机制
• 超时设置：局域网2-3秒，公网5-10秒
• 异常处理：捕获IOException，区分连接异常和数据异常
• 数据缓存：使用采集服务缓存数据，避免频繁读取PLC
• 日志记录：记录通讯日志，包括请求、响应、异常，便于排查
• 连接池：多PLC场景使用连接管理器统一管理
• 地址规划：提前规划寄存器地址，避免冲突，编写地址映射文档
• 测试验证：先用Modbus Poll等工具确认通讯正常，再集成Java代码

九、各品牌PLC Modbus地址参考

本文提供的Java代码实现了与PLC的完整Modbus TCP通讯功能，包括连接管理、自动重连、批量读写、多种数据类型转换、数据采集服务以及Spring Boot集成方案。代码可直接用于工业自动化项目开发，建议先使用Modbus Poll工具确认PLC通讯参数和地址映射，再将Java代码集成到实际项目中。
